RB-Interior trim window

Frame: Durable & Light weight environment friendly PVC frame. Color: Warm white, can be customized. Pull rod: Durable and high strength aluminum alloy with oxidation treatment surface. Push handle operate with the rod lock smoothly.

Classification

RV doors and windows

Keywords

Online Inquiry

features and functions

Product Features

●Frame: Durable & Light weight environment friendly PVC frame.

●Color: Warm white, can be customized.

●Pull rod: Durable and high strength aluminum alloy with oxidation treatment surface. Push handle operate with the rod lock smoothly.

●Curtain: Pleated type with good wind resistance, beautiful.

●Open: Simple lock structure, the lock cover can be opened by pressing it lightly with one hand, and the two pullrods can be locked automatically by quick collision. Shading cloth and window screen can be stopped and locked at any position.

Main Functions

●RB-1 Roller blind interior window.

●Windproof structure design.

●Patented design structure for smooth and gentle operation Silent design, no noise during operation and vibration.

●Pull rod: Durable and high strength aluminum alloy with oxidation treatment surface.

Specifications

Window Specification PW-H-W FPW-H-W	RB -\| Interior window dimension/mm(H 76)-(W 41)	Cut hole size (H+3)-(W+3)	Remarks
PW-300-500	376-541	303-503
PW-350-600	426-641	353-603
PW-450-500	526-541	453-503
PW-450-610	526-641	453-613
PW-450-900	526-941	453-903
PW-450-1000	526-1041	453-1003
PW-450-1100	526-1141	453-1103
PW-500-900	576-941	503-903
PW-500-1200	576-1241	503-1203
PW-900-900	976-941	903-903
FPW-350-500	426-541	353-503
FPW-450-500	526-541	453-503
FPW-450-610	526-651	453-613
FPW-450-900	526-941	453-903
FPW-450-1100	526-1141	453-1103
FPW-500-500	576-541	503-503
FPW-500-900	576-941	503-903

H: Height of window mounting surface. unit: mm;
W: Width of window mounting surface, unit: mm.
Shipped with existing specifications PW/FPW extruded window;
Or customized separately according to H or W size.
